纯CSS3百叶窗式切换轮播图特效

PetitQ 图片/图形 2019-5-07 1.64K 0 0

这是一款使用纯 CSS3 制作的百叶窗式切换轮播图特效。该特效使用背景图片来制作，在轮播图切换时，通过一组 div 元素来制作百叶窗效果，非常的炫酷。

HTML 结构

该轮播图特效中使用了 6 张背景图片，HTML 结构如下：

也想出现在这里？联系我们吧

```
<div class="slider">
```
```
  <div class="captions">
```
```
    <div class="c1">duzy fiat</div>
```
```
    <div class="c2">syrenka</div>
```
```
    <div class="c3">wartburg</div>
```
```
    <div class="c4">warszawa</div>
```
```
    <div class="c5">wolga</div>
```
```
    <div class="c6">polonez</div>
```
```
  </div>
```
```
  <div class="img img1">
```
```
    <div class="frag frag1"></div>
```
```
    <div class="frag frag2"></div>
```
```
    <div class="frag frag3"></div>
```
```
    <div class="frag frag4"></div>
```
```
    <div class="frag frag5"></div>
```
```
    <div class="frag frag6"></div>
```
```
  </div>
```
```
  <div class="img img2">
```
```
    <div class="frag frag1"></div>
```
```
    <div class="frag frag2"></div>
```
```
    <div class="frag frag3"></div>
```
```
    <div class="frag frag4"></div>
```
```
    <div class="frag frag5"></div>
```
```
    <div class="frag frag6"></div>
```
```
  </div>
```
```
  <div class="img img3">
```
```
    <div class="frag frag1"></div>
```
```
    <div class="frag frag2"></div>
```
```
    <div class="frag frag3"></div>
```
```
    <div class="frag frag4"></div>
```
```
    <div class="frag frag5"></div>
```
```
    <div class="frag frag6"></div>
```
```
  </div>
```
```
  <div class="img img4">
```
```
    <div class="frag frag1"></div>
```
```
    <div class="frag frag2"></div>
```
```
    <div class="frag frag3"></div>
```
```
    <div class="frag frag4"></div>
```
```
    <div class="frag frag5"></div>
```
```
    <div class="frag frag6"></div>
```
```
  </div>
```
```
  <div class="img img5">
```
```
    <div class="frag frag1"></div>
```
```
    <div class="frag frag2"></div>
```
```
    <div class="frag frag3"></div>
```
```
    <div class="frag frag4"></div>
```
```
    <div class="frag frag5"></div>
```
```
    <div class="frag frag6"></div>
```
```
  </div>
```
```
  <div class="img img6">
```
```
    <div class="frag frag1"></div>
```
```
    <div class="frag frag2"></div>
```
```
    <div class="frag frag3"></div>
```
```
    <div class="frag frag4"></div>
```
```
    <div class="frag frag5"></div>
```
```
    <div class="frag frag6"></div>
```
```
  </div>
```
```
</div>
```

另外使用 6 个 Radio 按钮作为轮播图的切换按钮：

<input type="radio" name="slides" id="slide1" checked>

<input type="radio" name="slides" id="slide2">

<input type="radio" name="slides" id="slide3">

<input type="radio" name="slides" id="slide4">

<input type="radio" name="slides" id="slide5">

<input type="radio" name="slides" id="slide6">

CSS 样式

轮播图的基本 CSS 样式如下：

```
.slider, .img {
```
```
  width: inherit;
```
```
  height: inherit;
```
```
}
```
```
.slider {
```
```
  position: relative;
```
```
  overflow: hidden;
```
```
  background-color: #000;
```
```
  border: 8px solid #eee;
```
```
  border-radius: 5px;
```

  box-shadow: 0 7px 20px rgba(0,0,0,.5);

```
}
```
```
.img {
```
```
  position: absolute;
```
```
  margin-left: -8px;
```
```
  perspective: 500px;
```
```
}
```
```
.frag {
```
```
  width: 150px;
```
```
  height: inherit;
```
```
  float: left;
```
```
  opacity: 0;
```
```
  z-index: 0;
```
```
  transform-origin: center right;
```

  transform: rotateY(90deg) translateZ(100px) scale(1.5);

  transition: transform .6s, opacity .6s, -webkit-filter 2s ease-out;

  -webkit-filter: saturate(0) blur(10px) brightness(.6) contrast(4);

```
}
```
```
.img .frag2 {
```
```
  background-position: -150px 0;
```
```
  transition-delay: .2s;
```
```
}
```
```
.img .frag3 {
```
```
  background-position: -300px 0;
```
```
  transition-delay: .4s;
```
```
}
```
```
.img .frag4 {
```
```
  background-position: -450px 0;
```
```
  transition-delay: .6s;
```
```
}
```
```
.img .frag5 {
```
```
  background-position: -600px 0;
```
```
  transition-delay: .8s;
```
```
}
```
```
.img .frag6 {
```
```
  background-position: -750px 0;
```
```
  transition-delay: 1s;
```
```
}
```

轮播图中使用的背景图片样式如下：

.img1 .frag { background-image: url(1.jpg) }

.img2 .frag { background-image: url(2.jpg) }

.img3 .frag { background-image: url(3.jpg) }

.img4 .frag { background-image: url(4.jpg) }

.img5 .frag { background-image: url(5.jpg) }

.img6 .frag { background-image: url(6.jpg) }

轮播图控制按钮的 CSS 样式如下：

#slide1:checked ~ .slider .img1 .frag, #slide2:checked ~ .slider .img2 .frag, #slide3:checked ~ .slider .img3 .frag, #slide4:checked ~ .slider .img4 .frag, #slide5:checked ~ .slider .img5 .frag, #slide6:checked ~ .slider .img6 .frag {

  transform: rotateY(0) translateZ(0) scale(1);

  -webkit-filter: saturate(1) blur(0) brightness(1) contrast(1);

```
  opacity: 1;
```
```
  z-index: 1;
```
```
}
```
```

```
```
.controls {
```
```
  position: absolute;
```
```
  bottom: -50px;
```
```
  left: 50%;
```

  margin-left: -115px; /*(6elem30px+5el10px)/2=115px*/

```
}
```
```

```
```
.controls label {
```
```
  display: block;
```
```
  height: 10px;
```
```
  width: 30px;
```
```
  float: left;
```
```
  background-color: #000;
```
```
  margin-right: 10px;
```
```
  cursor: pointer;
```
```
  opacity: .2;
```
```
  transition: opacity .5s;
```
```
}
```
```

```

.controls label:hover, .side-controls label:hover,

#slide1:checked ~ .controls label:nth-of-type(1),

#slide2:checked ~ .controls label:nth-of-type(2),

#slide3:checked ~ .controls label:nth-of-type(3),

#slide4:checked ~ .controls label:nth-of-type(4),

#slide5:checked ~ .controls label:nth-of-type(5),

#slide6:checked ~ .controls label:nth-of-type(6) { opacity: .8; }

```

```
```
.side-controls label {
```
```
  position: absolute;
```
```
  display: block;
```
```
  border-top: 30px solid transparent;
```

  border-bottom: 30px solid transparent;

```
  top: 50%;
```
```
  margin-top: -15px;
```
```
  cursor: pointer;
```
```
  opacity: .2;
```
```
  transition: opacity .5s;
```
```
}
```
```

```

#slide1:checked ~ .side-controls label:nth-of-type(6),

#slide2:checked ~ .side-controls label:nth-of-type(1),

#slide3:checked ~ .side-controls label:nth-of-type(2),

#slide4:checked ~ .side-controls label:nth-of-type(3),

#slide5:checked ~ .side-controls label:nth-of-type(4),

#slide6:checked ~ .side-controls label:nth-of-type(5) {

```
  left: -40px;
```
```
  border-right: 40px solid #000;
```
```
}
```
```

```

#slide1:checked ~ .side-controls label:nth-of-type(2),

#slide2:checked ~ .side-controls label:nth-of-type(3),

#slide3:checked ~ .side-controls label:nth-of-type(4),

#slide4:checked ~ .side-controls label:nth-of-type(5),

#slide5:checked ~ .side-controls label:nth-of-type(6),

#slide6:checked ~ .side-controls label:nth-of-type(1) {

```
  right: -40px;
```
```
  border-left: 40px solid #000;
```
```
}
```
```

```

#slide2:checked ~ .slider .captions .c2,

#slide1:checked ~ .slider .captions .c1,

#slide3:checked ~ .slider .captions .c3,

#slide4:checked ~ .slider .captions .c4,

#slide5:checked ~ .slider .captions .c5,

#slide6:checked ~ .slider .captions .c6 { text-shadow: 0 0 0 rgba(255,255,255,.9) }

最后为图片标题设置 CSS 样式：

```
.captions > div {
```
```
  position: absolute;
```
```
  right: 20px;
```
```
  bottom: 7px;
```
```
  color: transparent;
```
```
  text-shadow: 0 0 60px transparent;
```
```
  font-size: 3em;
```
```
  z-index: 1;
```
```
  text-transform: uppercase;
```
```
  transition: text-shadow 2s;
```
```
}
```

Github 地址：https://github.com/andrzejbajuk79/slider-pure-css
